PULSE M
Wireless Multi-Room Music Streaming Speaker
The PULSE M takes the sight and sound of Hi-Fi enjoyment to new horizons with its unique Omni-Hybrid™ driver design and contemporary aesthetic.
General
Max Power Consumption: 79W
Storage Environment:
-10°C to 50°C, 20% to 80% relative humidity
Operating Environment: 0°C to 40°C
Finish: Black/White; Matte Satin Paint
Version: P230
Product Dimensions:
171 x 204 x 149 mm (W x H x D)
6.7 x 8 x 5.9 in (W x H x D)
Weight: 2.54kg/5.6lbs
Included Accessories:
120V AC Power Cord
230V AC Power Cord
Ethernet Cable
TOSLINK Optical to 3.5mm Mini Adapter
Safety/Warranty Guide
Quick Setup Guide
Audio
Supported Audio File Formats:
MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS
Supported Hi-Res Audio File Formats:
FLAC, MQA, WAV, AIFF, MPEG-4 SLS
Native Sampling Rates: up to 192 kHz
Bit Depth: 16-24
Audio Controls & EQ: BluOS Controller App
Distortion: THD+N, 0.030%
Amplification: Smart DSP Amplifier
Rated Power Output:
80W total system power, dual amp
50W x 1 Woofer; 15W x 2 Tweeter
Speakers:
5.25" (133mm) x 1 Woofer; 0.75" (19mm) x 2 Tweeter
Frequency Response:
60Hz-20kHz ±1.5 dB, -10 dB @ 40Hz
Software & Integration
Operating System: BluOS
App Controller Operating System:
iOS, Android, Windows, macOS
Processor: ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core
Supported Network File Sharing:
Server Message Block (SMB) up to 200,000 files
Album Art Supported: JPG, PNG
Music Services & Internet Radio: 23+ Click Here
3rd-Party Integrations: AirPlay 2
Spotify Connect
Tidal Connect
Roon Ready
Control System Integrations:
Crestron, Control4, RTI, ELAN, URC, Lutron
Voice Control Integrations:
Amazon Alexa Skills
BluOS Home Theater:
Use as rear surround channels
Connections
Power Supply: Universal bi-pin AC cord input (100-240AC)
Ethernet/LAN: Ethernet RJ45, Gigabit 1000 Mbps
Wi-Fi Built In: Wi-Fi 5 (802.11ac), dual-band
Bluetooth Quality: Bluetooth 5.0 aptX HD
IR Optical Built In:
IR Sensor Built In - front panel with IR Remote Learning
Optical/Analog Input: Combo - Mini TOSLINK/Stereo 3.5mm
USB IN: Type A (Fat32 Formatted)
Headphone Output: 3.5mm Stereo
Subwoofer Output: Wireless to PULSE SUB+
Frequency Response
Status Indicator: LED x 2
Play/Pause Button: Touch LED
Volume Control Buttons: Touch Slider LED
Previous/Next Track Buttons:
Touch LED
Preset Buttons: Touch LED x 5
Proximity Sensor: Yes
