Fibaro Smart Implant

Fibaro Smart Implant

Regular price £40.31
Regular price Sale price £40.31
Sale Sold out
Tax included.
Smart Implant allows to enhance the functionality of wired sensors and other devices by adding Z-Wave network communication. You can connect binary sensors, analog sensors, DS18B20 temperature sensors or DHT22 humidity and temperature sensor to report their readings to the Z-Wave controller. It can also control devices by opening/closing output contacts independently of the inputs.

Fibaro Smart Implant is a device manufactured by Fibaro, a Polish company that specializes in smart home automation products. The Fibaro Smart Implant is a small, modular device that can be installed in an electrical box behind a switch or socket to enable smart control of your lights and other devices. It allows you to control your lights and other connected devices from a smartphone app or voice assistant and can be integrated with other Fibaro products and smart home systems. The Fibaro Smart Implant is designed to be easy to install and use, with a simple plug-and-play design that doesn't require any wiring or special skills. It works by detecting the state of the switch or socket it is installed behind, and communicating that information to the Fibaro Home Center hub or other compatible smart home system. This enables you to control your lights and other connected devices from anywhere, and automate your home according to your preferences.

View full details


Smart Implant transforms your 'non-smart' devices into integral components of the FIBARO System. This revolutionary device empowers you to expand your system's capabilities like never before.


  • Compatibility: Compatible with any certified Z-Wave or Z-Wave Plus controller.
  • Security Modes: Supports Z-Wave network Security Modes: S0 with AES-128 encryption and S2 Authenticated with PRNG-based encryption.
  • Signal Repeater: Functions as a Z-Wave signal repeater.
  • Sensor Connectivity: Supports 6 DS18B20 sensors; Supports 1 DHT sensor; Supports 2 2-wire analog sensors; Supports 2 3-wire analog sensors.; Supports 2 binary sensors.
  • Built-in Temperature Sensor: Equipped with a built-in temperature sensor.

Technical Data

  • Power supply: 9-30V DC ±10%
  • Inputs: 2 0-10V or digital inputs 1 serial 1-wire input
  • Outputs: 2 potential-free outputs
  • Supported digital sensors: 6 DS18B20 or 1 DHT22
  • Maximum current on outputs: 150mA
  • Maximum voltage on outputs: 30V DC / 20V AC ±5%
  • Built-in temperature sensor measurement range: -55°C–126°C(-67°F–259°F)
  • Operating temperature: 0–40°C (32–104°F)
  • Radio protocol: Z-Wave (500 series chip)
  • Radio frequency: 868.4 or 869.8 MHz EU;908.4, 908.42 or 916.0 MHz US;921.4 or 919.8 MHz ANZ;869.0 MHz RU;
  • Radio transmits power max: 7 dBm (EIRP)
  • Range: up to 50m (164 ft) outdoors up to 40m (131 ft) indoors (depending on terrain and building structure)
  • Dimensions (Length x Width x Height): 29 x 18 x 13 mm (1.14” x 0.71” x 0.51”)
  • Compliance with EU directives: RoHS 2011/65/EURED 2014/53/EU
