Nice

Nice Smart - Control

Nice Smart - Control

301617040301
£54.91
£54.91
Sale Sold out
Tax included.

Smart-Control is a compact and straightforward installation device designed to elevate ordinary devices to a smart level. It serves as an ideal and budget-friendly answer for those seeking to incorporate alarm systems, sensors, thermostats, gates, or rolling shutters into their smart home setup.

Operating Smart-Control is conveniently achieved through the Yubii Home app, allowing for remote access and management of its functions. Moreover, Smart-Control has the added capability of extending the signal through Yubii Home or other compatible gateways from various brands.

View full details

Features

  • Compatible with any Z-Wave or Z-Wave Plus certified control system.
  • It supports Z-Wave network security modes: S0 with AES-128 encryption and S2 with PRNG encryption.
  • Works as a Z-Wave signal repeater.
  • The following sensors can be connected: 6 x DS18B20 sensors,1 x DHT sensor,2 x 2-wire analogue sensors,2 x 3-wire analogue sensors,2 x binary sensors.
  • Built-in temperature sensor

TECHNICAL SPECIFICATIONS

Power supply: 9-30V DC ±10%
Inputs: 2 x 0-10 analogue/binary inputs - 1 x 1-wire serial input (for DHT22 or
DS18B20 sensors)
Outputs: 2 x potential-free outputs (to control external circuits)
Supported digital sensors: 6 x DS18B20 or 1 x DHT22
Maximum current on outputs: 150 mA
Maximum voltage on outputs: 30V DC/ 20V AC 5%
Operating temperature: (°C Min/Max) 0 - 40
Radio protocol Z-Wave: (500 series)
Radio frequency: (MHz) 868.4 lub 869.8 (EU) / 908.4, 908.42 or 916.0 (US) / 921.4 lub 919.8 (ANZ)
/ 869.0 (RU)
Compliant with European directives: RoHS 2011/65/EU - RED 2014/53/EU
Radio range: up to 40m (depending on building structure)
Dimensions (mm): 29 x 18 x 13 h
