SPECIFICATIONS
- In-room frequency response: 18Hz – 180Hz +/- 3db
- Digital power amp: 300 Watts RMS, 600 Watts max.
- Phase: 0/180 switch
- Low pass: 50 to 180Hz, continuously variable with LFE by-pass switch
- High pass: 100Hz fixed, 1st order on high-level output
- Bass EQ: 0, +3dB, +6dB 25 Hz center frequency
- Power: Auto/On/Off: toggle Switch
- Dimensions: 275mm (W) x 305mm (H) x 345mm (D)
- Enclosure type: Hardened steel with S2 Bass loading
- Connections: 2 female RCA phono inputs and 2 female RCA phono outputs (pass-thru) 5-way gold plated binding posts
- Woofer: 10″ long throw ceramic coated aluminum
- Warranty: 2 Years Parts and Labour
