Build Features


Hardware Specifications
- Networking interface: (2) GbE RJ45 ports
- Power method: PoE+Power supply
- Gigabit PoE adapter: 48V DC, 0.5A**5-packs do not come with PoE adapters.
- Supported voltage range: 44—57 VDC
- Max. power consumption: 17W
- Max. TX power: 2.4 GHz: 25 dBm | 5 GHz: 25 dBm
- MIMO: 2.4 GHz: 4 x 4 | 5 GHz: 4 x 4
- Throughput rate: 2.4 GHz: 800 Mbps | 5 GHz: 1733 Mbps
- Antenna gain: 2.4 GHz: 3 dBi | 5 GHz: 4 dBi
- Button: Factory reset
- Mounting: Wall/ceiling (Included)
- Operating temperature: -10 to 70° C (14 to 158° F)
- Operating humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC

Software Specification
- WiFi standards: 802.11a/b/g/n/ac/ac-Wave2
- Wireless security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
- BSSID: Up to 8 per radio
- VLAN: 802.1Q
- Advanced QoS: Per-user rate limiting
- Power save: Supported
- Guest traffic isolation: Supported
- WMM: Supported
- Concurrent clients: 500+
