Hardware Specifications
- Management interface: Ethernet In-Band
- Networking interface: (8) 10G SFP+ ports
- Total non-blocking throughput: 80 Gbps
- Switching capacity: 160 Gbps
- Forwarding rate:119.04 Mpps
- Power method: Universal input, 100—240V AC, 50/60 Hz
- Power supply: AC/DC, internal, 36W
- Supported voltage range: 100—240V AC
- Max. power consumption: 30W
- ESD/EMP protection: Air: ± 16kV, contact: ± 12kV

Hardware Specifications
- Max. number of supported SFP+ modules: UACC-OM-MM-10G: 8 | UACC-OM-SM-10G: 8 | UACC-CM-RJ45-10G: 4 | UACC-CM-RJ45-MG: 4
- Services: SMB Layer 2 GbE switch
- LCM display: (1) 1.3" LCM color touchscreen
- Button: Factory reset
- Operating temperature: -5 to 40° C (23 to 104° F)
- Operating humidity: 10 to 90% noncondensing
- Certifications: CE, FCC, IC
