Ubiquiti
UFP-VIEWPORT
UFP-VIEWPORT
Couldn't load pickup availability
The Ubiquiti UniFi Protect ViewPort is a live view applicance that allows you to view your UniFi Protect camera feeds on an HDMI display. It uses Power over Ethernet and connects to the local network hosting your cameras and connects via HDMI.
The Ubiquiti UniFi Protect ViewPort is a device used to display video feeds from UniFi Protect cameras. The ViewPort provides a convenient and compact way to view live camera feeds and recorded footage, without the need for a computer or other display device. The ViewPort features a 7-inch touchscreen display, making it easy to navigate and view your camera feeds. It is designed to be mounted on a wall or placed on a flat surface and can be powered using a PoE (Power over Ethernet) connection. With the Ubiquiti UniFi Protect ViewPort, you can keep an eye on your property and loved ones from anywhere in your home, without the need for a bulky computer setup.
| Mechanical Specifications | |
|---|---|
| Dimensions | 157 x 52 x 37 mm (6.18 x 2.05 x 1.46") |
| Weight | Without mount: 230 g (8.11 oz) With TV mount: 252 g (8.89 oz) |
| Enclosure material | Polycarbonate |
| Mount material | Polycarbonate |
Mfr. Part #: UFP-VIEWPORT
Deployment
Build Features
Hardware Specifications
- Processor: Octa-core ARM®
- Memory: 4 GB low power DDR4X
- Networking interface: GbE RJ45 port
- Power method: PoE
- Max. power consumption: 9.5W
- ESD/EMP protection: Air: ± 8kV, contact: ± 4kV
- Bluetooth: 5.0
- Antennas: Bluetooth
- Antenna gain: 2 dB
- Button: Factory-reset
- Operating temperature: 0 to 40° C (32 to 104° F)
- Operating humidity: 20 to 80% noncondensing
- Certifications: FCC, IC, CE
Software Specifications
System & Audo Specs
Web application:
UniFi Protect
Mobile app:
UniFi Protect iOS™ and Android™
