Optics & Video Specs
Optics
- Sensor: 2MP HDR sensor
- Lens: EFL 4 mm, f/2.0
- View angle: Lens correction off: H: 87°, V: 47°, D: 104° | Lens correction on: H: 80°, V: 46°, D: 92°
- Night mode: Built-in IR LED illumination and IR Cut filter
Video
- Video compression: H.264
- Resolution: 2MP 1920 x 1080 (16:9)
- Max. frame rate: 25 FPS
- Image settings: Brightness, contrast, sharpness, saturation, noise reduction, 50/60 Hz
Software Specification
System
Networking interface: 10/100 MbE RJ45 port
Max. power consumption: 4W
Power method: PoE
Supported voltage range: 48V DC
Button: Factory reset
Mounting: Desktop, pole mount (Included)Ceiling, pendant, professional wall mount (Sold separately)
Operating temperature: -20 to 40° C (-4 to 104° F)
Operating humidity: 20 to 90% noncondensing
Certifications: FCC, IC, CE
Audio
- Microphone: Yes (Can be disabled)
